An R package containing commonly used functions for analyzing behavioral economic discounting data.
The package began as a set of scoring and curve-fitting tools. It supports scoring of the 21- and 27-Item Monetary Choice Questionnaires (see Kaplan et al., 2016) and the 30-item Probability Discounting Questionnaire (see Madden et al., 2009), calculating k values (and Area Under the Curve metrics) from indifference points using nonlinear regression (Mazur’s simple hyperbola and exponential), and scoring of the minute discounting task (see Koffarnus & Bickel, 2014) using the Qualtrics 5-trial discounting template (see the Qualtrics Minute Discounting User Guide), which is also available as a .qsf file in this package.
It also fits discounting models: a mixed-effects (hierarchical) tier
via Template Model Builder (fit_dd_tmb()), a trial-level choice model
(fit_dd_choice()), a Bayesian tier via brms (fit_dd_brms()), and
Monte Carlo power analysis for between-subject designs
(power_discounting()). These modeling tiers, together with 21-item MCQ
and 30-item PDQ scoring, are included in version 0.4.0, which is being
submitted to CRAN; the CRAN release available today is 0.3.2, which
contains only the scoring and NLS tools (see Installing, below, for how
to get each version). Full documentation, including worked vignettes, is
available at the package
website.
The package spans several tiers. Find the row that matches your data and question, then follow the vignette for a worked example:
| Your data / question | Function(s) | Vignette |
|---|---|---|
| 21- or 27-Item Monetary Choice Questionnaire |
score_mcq() (score_mcq27() for 27-item only) |
MCQ scoring |
| 30-item Probability Discounting Questionnaire | score_pdq() |
PDQ scoring |
| Indifference points, individual or aggregate (NLS) |
fit_dd() / results_dd()
|
Delay discounting basics |
| Indifference points, mixed-effects (borrows strength across subjects) | fit_dd_tmb() |
Mixed-effects with TMB |
| Indifference points at exactly 0 or 1 | fit_dd_tmb(family = "sltb") |
Bounded error distributions |
| Comparing discount rates between groups |
get_dd_param_emms() / get_dd_comparisons()
|
Group comparisons |
| Trial-level smaller-sooner vs. larger-later choices | fit_dd_choice() |
Choice-based discounting |
| Bayesian versions of the model tiers |
fit_dd_brms() / fit_dd_choice_brms()
|
Bayesian discounting |
| 5.5-trial delay or probability task |
calc_dd() / calc_pd()
|
5.5-trial task |
Currently, this version (0.4.0) appears stable. I encourage you to use it but be aware that, as with any software release, there might be (unknown) bugs present. I’ve tried hard to make this version usable while including the core functionality (described more below). However, if you find issues or would like to contribute, please open an issue on my GitHub page or email me.
You may also use these functions in the Shinybeez web application and also found at the GitHub page.
If you use this package in your own work, please consider citing the package:
Kaplan, B. A. (2026). beezdiscounting: Behavioral Economic Easy Discounting. R package version 0.4.0, https://github.com/brentkaplan/beezdiscounting
You can also find the latest citation using
citation("beezdiscounting")
The latest CRAN release of beezdiscounting can be found on
CRAN and installed
using the following command. The first time you install the package, you
may be asked to select a CRAN mirror. Simply select the mirror
geographically closest to you. (CRAN lags this repository’s develop
branch: check CRAN
or packageVersion("beezdiscounting") for the version you’ll actually
get.)
install.packages("beezdiscounting")
library(beezdiscounting)
The develop branch on
GitHub is always the
most current version and carries any modeling tiers or features (e.g.
fit_dd_tmb(), fit_dd_choice(), fit_dd_brms(),
power_discounting()) that have not yet reached CRAN. First install and
load the devtools package, then use install_github to install the
package and its vignettes. You don’t need to download anything
directly from GitHub:
install.packages("devtools")
devtools::install_github("brentkaplan/beezdiscounting", build_vignettes = TRUE)
library(beezdiscounting)
The walkthrough below uses the 27-item MCQ (Kirby, Petry, & Bickel,
1999) via score_mcq27(). The original 21-item MCQ (Kirby & Marakovic,
1996) is scored the same way with score_mcq(dat, items = 21); see the
MCQ scoring
vignette
for a 21-item example built on the bundled mcq21 dataset.
An example dataset of responses on the 27-Item Monetary Choice
Questionnaire is provided. This object is called mcq27 and is located
within the beezdiscounting package. These data are the example data
used in the paper by Kaplan et al,
2016. Note the
format of the data, which is called “long format”. Long format data are
data structured such that repeated observations are stacked in multiple
rows, rather than across columns.
| subjectid | questionid | response | |
|---|---|---|---|
| 1 | 1 | 1 | 0 |
| 2 | 1 | 2 | 0 |
| 3 | 1 | 3 | 0 |
| 4 | 1 | 4 | 1 |
| 5 | 1 | 5 | 1 |
| 6 | 1 | 6 | 0 |
| 7 | 1 | 7 | 1 |
| 28 | 2 | 1 | 0 |
| 29 | 2 | 2 | 1 |
| 30 | 2 | 3 | 1 |
| 31 | 2 | 4 | 1 |
| 32 | 2 | 5 | 1 |
| 33 | 2 | 6 | 0 |
| 34 | 2 | 7 | 1 |
The first column contains the subject id. The second column contains the question id. The third column contains the response (0 for smaller sooner, 1 for larger later)
beezdiscounting includes several helper functions to reshape data.
long_to_wide_mcq()Long format data are widened such that subject id is the first column and each subsequent column contains the response associated with the question (specified as column names).
wide <- long_to_wide_mcq(generate_data_mcq(2))
knitr::kable(wide[, c(1:5, 24:28)], caption = "Wide Format Data")
| subjectid | 1 | 2 | 3 | 4 | 23 | 24 | 25 | 26 | 27 |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 0 |
| 2 | 1 | 1 | 1 | 0 | 1 | 1 | 1 | 1 | 1 |
Wide Format Data
wide_to_long_mcq()Wide data (see example of wide data above) are made long such that subject id is in the first column, question id (inferred from the column names from the wide format dataframe) is the second column, and the response is the third column.
long <- wide_to_long_mcq(wide, items = 27)
knitr::kable(long[c(1:5, 28:32), ], caption = "Long Format Data")
| subjectid | questionid | response |
|---|---|---|
| 1 | 1 | 1 |
| 1 | 2 | 1 |
| 1 | 3 | 1 |
| 1 | 4 | 1 |
| 1 | 5 | 0 |
| 2 | 1 | 1 |
| 2 | 2 | 1 |
| 2 | 3 | 1 |
| 2 | 4 | 0 |
| 2 | 5 | 1 |
Long Format Data
wide_to_long_mcq_excel()A different ‘type’ of wide data is that used in the 27-Item Monetary
Choice Questionnaire Automated Excel Scorer (Kaplan et al,
2016). In this
format, the first column is the question id and each subsequent column
represents a subject (as the column name) and the response in rows (see
the example below). This function takes the data from that format and
converts it to the format needed for beezdiscounting functions.
knitr::kable(wide_excel[c(1:5, 22:27), ],
caption = "Format Expected in the 27-Item MCQ Excel Scorer")
| questionid | 1 | 2 |
|---|---|---|
| 1 | 1 | 1 |
| 2 | 1 | 1 |
| 3 | 1 | 1 |
| 4 | 1 | 0 |
| 5 | 0 | 1 |
| 22 | 1 | 0 |
| 23 | 1 | 1 |
| 24 | 1 | 1 |
| 25 | 1 | 1 |
| 26 | 1 | 1 |
| 27 | 0 | 1 |
Format Expected in the 27-Item MCQ Excel Scorer
long_excel <- wide_to_long_mcq_excel(wide_excel)
knitr::kable(long_excel[c(1:5, 28:32), ], caption = "Long Format")
| subjectid | questionid | response |
|---|---|---|
| 1 | 1 | 1 |
| 1 | 2 | 1 |
| 1 | 3 | 1 |
| 1 | 4 | 1 |
| 1 | 5 | 0 |
| 2 | 1 | 1 |
| 2 | 2 | 1 |
| 2 | 3 | 1 |
| 2 | 4 | 0 |
| 2 | 5 | 1 |
Long Format
long_to_wide_mcq_excel()Data can be manipulated from long form into a form used by the 27-Item Monetary Choice Questionnaire Automated Excel Scorer.
wide_excel <- long_to_wide_mcq_excel(long_excel)
knitr::kable(wide_excel[c(1:5, 22:27), ],
caption = "Format Expected in the 27-Item MCQ Excel Scorer")
| questionid | 1 | 2 |
|---|---|---|
| 1 | 1 | 1 |
| 2 | 1 | 1 |
| 3 | 1 | 1 |
| 4 | 1 | 0 |
| 5 | 0 | 1 |
| 22 | 1 | 0 |
| 23 | 1 | 1 |
| 24 | 1 | 1 |
| 25 | 1 | 1 |
| 26 | 1 | 1 |
| 27 | 0 | 1 |
Format Expected in the 27-Item MCQ Excel Scorer
Generate data specifying reproducibility and proportion of NA
responses.
## fake data with no missing values
fake_data_no_missing <- generate_data_mcq(n_ids = 2, n_items = 27,
seed = 1234, prop_na = 0)
knitr::kable(fake_data_no_missing, caption = "Fake Data - No Missings")
| subjectid | questionid | response |
|---|---|---|
| 1 | 1 | 1 |
| 1 | 2 | 1 |
| 1 | 3 | 1 |
| 1 | 4 | 1 |
| 1 | 5 | 0 |
| 1 | 6 | 1 |
| 1 | 7 | 0 |
| 1 | 8 | 0 |
| 1 | 9 | 0 |
| 1 | 10 | 1 |
| 1 | 11 | 1 |
| 1 | 12 | 1 |
| 1 | 13 | 1 |
| 1 | 14 | 0 |
| 1 | 15 | 1 |
| 1 | 16 | 1 |
| 1 | 17 | 1 |
| 1 | 18 | 0 |
| 1 | 19 | 1 |
| 1 | 20 | 1 |
| 1 | 21 | 1 |
| 1 | 22 | 1 |
| 1 | 23 | 1 |
| 1 | 24 | 1 |
| 1 | 25 | 1 |
| 1 | 26 | 1 |
| 1 | 27 | 0 |
| 2 | 1 | 1 |
| 2 | 2 | 1 |
| 2 | 3 | 1 |
| 2 | 4 | 0 |
| 2 | 5 | 1 |
| 2 | 6 | 0 |
| 2 | 7 | 0 |
| 2 | 8 | 0 |
| 2 | 9 | 1 |
| 2 | 10 | 0 |
| 2 | 11 | 1 |
| 2 | 12 | 1 |
| 2 | 13 | 0 |
| 2 | 14 | 1 |
| 2 | 15 | 0 |
| 2 | 16 | 1 |
| 2 | 17 | 1 |
| 2 | 18 | 1 |
| 2 | 19 | 0 |
| 2 | 20 | 0 |
| 2 | 21 | 0 |
| 2 | 22 | 0 |
| 2 | 23 | 1 |
| 2 | 24 | 1 |
| 2 | 25 | 1 |
| 2 | 26 | 1 |
| 2 | 27 | 1 |
Fake Data - No Missings
## fake data with missing values
fake_data_missing <- generate_data_mcq(n_ids = 2, n_items = 27,
seed = 1234, prop_na = .1)
knitr::kable(fake_data_missing, caption = "Fake Data - Missings")
| subjectid | questionid | response |
|---|---|---|
| 1 | 1 | 1 |
| 1 | 2 | NA |
| 1 | 3 | 1 |
| 1 | 4 | 1 |
| 1 | 5 | 0 |
| 1 | 6 | 1 |
| 1 | 7 | 0 |
| 1 | 8 | 0 |
| 1 | 9 | 0 |
| 1 | 10 | 1 |
| 1 | 11 | 1 |
| 1 | 12 | 1 |
| 1 | 13 | 1 |
| 1 | 14 | 0 |
| 1 | 15 | NA |
| 1 | 16 | 1 |
| 1 | 17 | 1 |
| 1 | 18 | 0 |
| 1 | 19 | 1 |
| 1 | 20 | 1 |
| 1 | 21 | 1 |
| 1 | 22 | 1 |
| 1 | 23 | 1 |
| 1 | 24 | 1 |
| 1 | 25 | 1 |
| 1 | 26 | 1 |
| 1 | 27 | 0 |
| 2 | 1 | 1 |
| 2 | 2 | 1 |
| 2 | 3 | 1 |
| 2 | 4 | 0 |
| 2 | 5 | 1 |
| 2 | 6 | 0 |
| 2 | 7 | 0 |
| 2 | 8 | 0 |
| 2 | 9 | 1 |
| 2 | 10 | 0 |
| 2 | 11 | NA |
| 2 | 12 | 1 |
| 2 | 13 | 0 |
| 2 | 14 | 1 |
| 2 | 15 | 0 |
| 2 | 16 | NA |
| 2 | 17 | 1 |
| 2 | 18 | 1 |
| 2 | 19 | 0 |
| 2 | 20 | 0 |
| 2 | 21 | 0 |
| 2 | 22 | NA |
| 2 | 23 | 1 |
| 2 | 24 | 1 |
| 2 | 25 | 1 |
| 2 | 26 | 1 |
| 2 | 27 | 1 |
Fake Data - Missings
MCQ data can be scored regularly and can also impute using various methods specified by Yeh et al, 2023
## normal scoring of data with no missing values
tbl1 <- score_mcq27(fake_data_no_missing)
| subjectid | overall_k | small_k | medium_k | large_k | geomean_k |
|---|---|---|---|---|---|
| 1 | 0.000158 | 0.000158 | 0.000158 | 0.000251 | 0.000185 |
| 2 | 0.000251 | 0.001562 | 0.004469 | 0.000158 | 0.001034 |
k Values
| subjectid | overall_consistency | small_consistency | medium_consistency | large_consistency | composite_consistency |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 1.000000 | 0.777778 |
| 2 | 0.629630 | 0.777778 | 0.555556 | 0.666667 | 0.666667 |
Consistency Scores
| subjectid | overall_proportion | small_proportion | medium_proportion | large_proportion | impute_method |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 0.888889 | none |
| 2 | 0.592593 | 0.555556 | 0.555556 | 0.666667 | none |
Proportions
## normal scoring of data with missings with no imputation
tbl2 <- score_mcq27(fake_data_missing)
| subjectid | overall_k | small_k | medium_k | large_k | geomean_k |
|---|---|---|---|---|---|
| 1 | NA | 0.000158 | 0.000158 | NA | NA |
| 2 | NA | NA | NA | 0.000158 | NA |
k Values
| subjectid | overall_consistency | small_consistency | medium_consistency | large_consistency | composite_consistency |
|---|---|---|---|---|---|
| 1 | NA | 0.666667 | 0.666667 | NA | NA |
| 2 | NA | NA | NA | 0.666667 | NA |
Consistency Scores
| subjectid | overall_proportion | small_proportion | medium_proportion | large_proportion | impute_method |
|---|---|---|---|---|---|
| 1 | NA | 0.666667 | 0.666667 | NA | none |
| 2 | NA | NA | NA | 0.666667 | none |
Proportions
This approach (Group Geometric Mean) “…calculates the composite k when at least one of the three amount set ks is fully available” (Yeh et al, 2023)
tbl3 <- score_mcq27(fake_data_missing, impute_method = "GGM")
| subjectid | overall_k | small_k | medium_k | large_k | geomean_k |
|---|---|---|---|---|---|
| 1 | NA | 0.000158 | 0.000158 | NA | 0.000158 |
| 2 | NA | NA | NA | 0.000158 | 0.000158 |
k Values
| subjectid | overall_consistency | small_consistency | medium_consistency | large_consistency | composite_consistency |
|---|---|---|---|---|---|
| 1 | NA | 0.666667 | 0.666667 | NA | NA |
| 2 | NA | NA | NA | 0.666667 | NA |
Consistency Scores
| subjectid | overall_proportion | small_proportion | medium_proportion | large_proportion | impute_method |
|---|---|---|---|---|---|
| 1 | NA | 0.666667 | 0.666667 | NA | GGM |
| 2 | NA | NA | NA | 0.666667 | GGM |
Proportions
This approach (Item Nearest Neighbor) “…replaces the missing value with the congruent non-missing responses to the items corresponding to the same k value” (Yeh et al, 2023)
tbl4 <- score_mcq27(fake_data_missing, impute_method = "INN")
| subjectid | overall_k | small_k | medium_k | large_k | geomean_k |
|---|---|---|---|---|---|
| 1 | 0.000158 | 0.000158 | 0.000158 | 0.000251 | 0.000185 |
| 2 | NA | NA | 0.063154 | 0.000158 | NA |
k Values
| subjectid | overall_consistency | small_consistency | medium_consistency | large_consistency | composite_consistency |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 1.000000 | 0.777778 |
| 2 | NA | NA | 0.666667 | 0.666667 | NA |
Consistency Scores
| subjectid | overall_proportion | small_proportion | medium_proportion | large_proportion | impute_method |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 0.888889 | INN |
| 2 | NA | NA | 0.444444 | 0.666667 | INN |
Proportions
This approach (Item Nearest Neighbor with Random) “… is identical to [INN no random component], except that when a missing response cannot be resolved, this datum will be randomly replaced with 0 or 1, corresponding to choosing immediate or delayed rewards, respectively” (Yeh et al, 2023)
tbl5 <- score_mcq27(fake_data_missing, impute_method = "INN",
random = TRUE)
| subjectid | overall_k | small_k | medium_k | large_k | geomean_k |
|---|---|---|---|---|---|
| 1 | 0.000158 | 0.000158 | 0.000158 | 0.000251 | 0.000185 |
| 2 | 0.000251 | 0.001562 | 0.063154 | 0.000158 | 0.002500 |
k Values
| subjectid | overall_consistency | small_consistency | medium_consistency | large_consistency | composite_consistency |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 1.000000 | 0.777778 |
| 2 | 0.592593 | 0.777778 | 0.666667 | 0.666667 | 0.703704 |
Consistency Scores
| subjectid | overall_proportion | small_proportion | medium_proportion | large_proportion | impute_method |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 0.888889 | INN with random |
| 2 | 0.555556 | 0.555556 | 0.444444 | 0.666667 | INN with random |
Proportions
You can also return a list when INN imputation with random is specified.
This is helpful to see what values replaced the missings (NAs) in the
original dataset.
lst <- score_mcq27(fake_data_missing, impute_method = "INN",
random = TRUE, return_data = TRUE)
The scoring summary metric dataframe as before (access via
...$results):
| subjectid | overall_k | small_k | medium_k | large_k | geomean_k |
|---|---|---|---|---|---|
| 1 | 0.000158 | 0.000158 | 0.000158 | 0.000251 | 0.000185 |
| 2 | 0.000251 | 0.001562 | 0.063154 | 0.000158 | 0.002500 |
k Values
| subjectid | overall_consistency | small_consistency | medium_consistency | large_consistency | composite_consistency |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 1.000000 | 0.777778 |
| 2 | 0.555556 | 0.666667 | 0.666667 | 0.666667 | 0.666667 |
Consistency Scores
| subjectid | overall_proportion | small_proportion | medium_proportion | large_proportion | impute_method |
|---|---|---|---|---|---|
| 1 | 0.740741 | 0.666667 | 0.666667 | 0.888889 | INN with random |
| 2 | 0.518519 | 0.444444 | 0.444444 | 0.666667 | INN with random |
Proportions
The original data and the new responses imputed (access via ...$data):
| subjectid | questionid | response | newresponse |
|---|---|---|---|
| 1 | 1 | 1 | 1 |
| 1 | 2 | NA | 1 |
| 1 | 3 | 1 | 1 |
| 1 | 4 | 1 | 1 |
| 1 | 5 | 0 | 0 |
| 1 | 6 | 1 | 1 |
| 1 | 7 | 0 | 0 |
| 1 | 8 | 0 | 0 |
| 1 | 9 | 0 | 0 |
| 1 | 10 | 1 | 1 |
| 1 | 11 | 1 | 1 |
| 1 | 12 | 1 | 1 |
| 1 | 13 | 1 | 1 |
| 1 | 14 | 0 | 0 |
| 1 | 15 | NA | 1 |
| 1 | 16 | 1 | 1 |
| 1 | 17 | 1 | 1 |
| 1 | 18 | 0 | 0 |
| 1 | 19 | 1 | 1 |
| 1 | 20 | 1 | 1 |
| 1 | 21 | 1 | 1 |
| 1 | 22 | 1 | 1 |
| 1 | 23 | 1 | 1 |
| 1 | 24 | 1 | 1 |
| 1 | 25 | 1 | 1 |
| 1 | 26 | 1 | 1 |
| 1 | 27 | 0 | 0 |
| 2 | 1 | 1 | 1 |
| 2 | 2 | 1 | 1 |
| 2 | 3 | 1 | 1 |
| 2 | 4 | 0 | 0 |
| 2 | 5 | 1 | 1 |
| 2 | 6 | 0 | 0 |
| 2 | 7 | 0 | 0 |
| 2 | 8 | 0 | 0 |
| 2 | 9 | 1 | 1 |
| 2 | 10 | 0 | 0 |
| 2 | 11 | NA | 0 |
| 2 | 12 | 1 | 1 |
| 2 | 13 | 0 | 0 |
| 2 | 14 | 1 | 1 |
| 2 | 15 | 0 | 0 |
| 2 | 16 | NA | 0 |
| 2 | 17 | 1 | 1 |
| 2 | 18 | 1 | 1 |
| 2 | 19 | 0 | 0 |
| 2 | 20 | 0 | 0 |
| 2 | 21 | 0 | 0 |
| 2 | 22 | NA | 0 |
| 2 | 23 | 1 | 1 |
| 2 | 24 | 1 | 1 |
| 2 | 25 | 1 | 1 |
| 2 | 26 | 1 | 1 |
| 2 | 27 | 1 | 1 |
Original Data and Imputed Data
The data must be in a dataframe with the following columns: - id:
participant ID - x: delay - y: indifference point
For example, the following data set is available in the package: dd_ip
knitr::kable(dd_ip[1:12, ], caption = "Indifference Point Data")
| id | x | y |
|---|---|---|
| P1 | 1 | 0.8162505 |
| P1 | 7 | 0.3908523 |
| P1 | 30 | 0.0191631 |
| P1 | 90 | 0.0990859 |
| P1 | 180 | 0.0134581 |
| P1 | 365 | 0.0035518 |
| P2 | 1 | 0.5724503 |
| P2 | 7 | 0.1652014 |
| P2 | 30 | 0.0326867 |
| P2 | 90 | 0.0802244 |
| P2 | 180 | 0.0275921 |
| P2 | 365 | 0.0247967 |
Indifference Point Data
The check_unsystematic() function checks whether the data conform to
the assumptions of the Johnson & Bickel (2008) method. As of the
development version it computes its two criteria per id, so you can
pass the whole data frame and get one row per participant
(single-subject input behaves as before):
unsys <- check_unsystematic(
dat = dd_ip,
ll = 1, # LL specification
c1 = 0.2, # Criterion 1 threshold
c2 = 0.1 # Criterion 2 threshold
)
knitr::kable(head(unsys, 5), caption = "Unsystematic Data Output")
| id | c1_pass | c2_pass |
|---|---|---|
| P1 | TRUE | TRUE |
| P2 | TRUE | TRUE |
| P3 | TRUE | TRUE |
| P4 | TRUE | TRUE |
| P5 | TRUE | TRUE |
Unsystematic Data Output
The fit_dd() function can be used to estimate k values from either
the simple hyperbola (Mazur, 1987) or exponential equation. The output
of this function can then be used in results_dd() and plot_dd() to
obtain a table of results and plots of data.
First use the fit_dd() function to fit the data:
dd_fit <- fit_dd(
dat = dd_ip,
equation = "Hyperbolic",
method = "Two Stage"
)
Then use the results_dd() function to get a table of results. The
results table automatically includes measures of Area Under the Curve
(AUC). Three different AUC measures are calculated:
auc_regular: AUC calculated using the regular trapezoidal rule
auc_log10: AUC calculated using the trapezoidal rule on the
log10-transformed x values (Borges et al., 2016)
auc_ord: AUC calculated using the trapezoidal rule on the ordinally
transformed x values (Borges et al., 2016)
dd_results <- results_dd(dd_fit) |>
dplyr::mutate(id = factor(id, levels = unique(dd_ip$id))) |>
dplyr::arrange(id) |>
dplyr::slice(1:5)
knitr::kable(dd_results[, c(1:7, 21:22)], caption = "Parameter Estimates and Information")
| method | id | term | estimate | std.error | statistic | p.value | conf_low | conf_high |
|---|---|---|---|---|---|---|---|---|
| Two Stage | P1 | k | 0.2481617 | 0.0432495 | 5.737907 | 0.0022525 | 0.1369853 | 0.3593381 |
| Two Stage | P2 | k | 0.7338717 | 0.0839848 | 8.738149 | 0.0003252 | 0.5179819 | 0.9497615 |
| Two Stage | P3 | k | 0.5551845 | 0.0810197 | 6.852465 | 0.0010110 | 0.3469168 | 0.7634522 |
| Two Stage | P4 | k | 0.2844655 | 0.0264744 | 10.744931 | 0.0001210 | 0.2164109 | 0.3525200 |
| Two Stage | P5 | k | 1.0135883 | 0.0760710 | 13.324235 | 0.0000426 | 0.8180415 | 1.2091351 |
Parameter Estimates and Information
knitr::kable(dd_results[, c(1:3, 8:17)], caption = "Model Information")
| method | id | term | sigma | isConv | finTol | logLik | AIC | BIC | deviance | df.residual | nobs | R2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Two Stage | P1 | k | 0.0529456 | TRUE | 0 | 9.664278 | -15.32856 | -15.74504 | 0.0140162 | 5 | 6 | 0.9735088 |
| Two Stage | P2 | k | 0.0324102 | TRUE | 0 | 12.609020 | -21.21804 | -21.63452 | 0.0052521 | 5 | 6 | 0.9769628 |
| Two Stage | P3 | k | 0.0419241 | TRUE | 0 | 11.064704 | -18.12941 | -18.54589 | 0.0087881 | 5 | 6 | 0.9715690 |
| Two Stage | P4 | k | 0.0278923 | TRUE | 0 | 13.509754 | -23.01951 | -23.43599 | 0.0038899 | 5 | 6 | 0.9917668 |
| Two Stage | P5 | k | 0.0205973 | TRUE | 0 | 15.328915 | -26.65783 | -27.07431 | 0.0021212 | 5 | 6 | 0.9886979 |
Model Information
knitr::kable(dd_results[, c(1:2, 18:20)], caption = "Area Under the Curve Values")
| method | id | auc_regular | auc_log10 | auc_ord |
|---|---|---|---|---|
| Two Stage | P1 | 0.0508842 | 0.2347151 | 0.1864921 |
| Two Stage | P2 | 0.0482794 | 0.1462015 | 0.1208656 |
| Two Stage | P3 | 0.0409701 | 0.1685302 | 0.1352153 |
| Two Stage | P4 | 0.0313241 | 0.2169982 | 0.1664288 |
| Two Stage | P5 | 0.0169814 | 0.1126664 | 0.0867586 |
Area Under the Curve Values
Finally, use the plot_dd() function to plot the data:
plot_dd(
fit_dd_object = dd_fit,
xlabel = "Delay (days)", # Specify x label
ylabel = "Indifference Point", # Specify y label
title = "Two Stage Plot", # Specify plot title
logx = TRUE # Specify log scale for x axis
)

Fitting each subject’s curve in isolation ignores that subjects are
samples from a population. fit_dd_tmb() estimates the population
discount rate and each subject’s rate at the same time, borrowing
strength across subjects so that noisy individuals are pulled toward the
group. It is fast (a Laplace approximation with automatic
differentiation, via Template Model Builder), and the
scale-location-truncated beta family (family = "sltb") handles
indifference points at exactly 0 or 1, where ordinary beta regression is
undefined.
Bring your own id/x/y data, or simulate from the same model with
simulate_dd_ip(), then fit a random intercept on the discount rate:
The code below is shown but not run in this README (the outputs are pasted beneath each chunk). Copy it into your session to reproduce.
sim <- simulate_dd_ip(
n_subjects = 15,
delays = c(7, 30, 90, 180, 365, 730),
log_k_pop = log(0.01),
sigma_u = 0.5,
phi = 10,
family = "sltb",
equation = "mazur",
seed = 1
)
fit <- fit_dd_tmb(sim, equation = "mazur", family = "sltb", random_effects = k ~ 1)
summary(fit)
TMB Mixed-Effects Discounting Model Summary
==================================================
Call:
fit_dd_tmb(data = sim, equation = "mazur", family = "sltb", random_effects = k ~
1)
Equation: mazur
Family: sltb
Backend: TMB_mixed
Convergence: Yes
Subjects: 15 Observations: 90
--- Fixed Effects (k) ---
term estimate std.error statistic p.value
k:(Intercept) 0.0103 0.0016 -30.0245 <2e-16
--- Variance Components ---
Component Estimate Scale
sigma_u (log10-k RE SD) 0.2287 log10
phi (precision) 12.3247 natural
--- Fit Statistics ---
Log-likelihood: 87.54
AIC: -169.08 BIC: -161.58
The fitted object carries the broom and base S3 surface: tidy(),
glance(), augment(), coef(), fixef(), ranef(), confint(),
predict(), logLik(), AIC(), and BIC(). ranef() returns each
subject’s deviation and their shrunken discount rate:
head(ranef(fit))
id u_i k
1 1 -0.58783897 0.007523599
2 10 0.15864424 0.011146530
3 11 0.93521791 0.016777805
4 12 0.05448851 0.010551646
5 13 -0.65165654 0.007274969
6 14 -2.33015497 0.003005893
Plotting the population curve over the per-subject indifference points shows the shrinkage at work:

The equation argument also accepts "exponential" and the
two-parameter hyperboloids "green-myerson" and "rachlin" (both
reduce to "mazur" at their shape exponent of 1), and
family = "gaussian" gives an unbounded-residual fit. For group
designs, pass factors = and use the estimated marginal means and
comparisons described below. The mixed-effects
vignette
walks through the full workflow.
When the data are trial-level smaller-sooner vs. larger-later choices
rather than indifference points, fit_dd_choice(mode = "structural")
estimates the discount rate k directly from the binary choices as a
binomial GLMM. Between-subject factors enter the log k design, and the
same post-hoc helpers (get_dd_param_emms(), get_dd_comparisons())
report marginal k per level and contrasts as ratios of discount rates:
ctrl <- simulate_dd_choice(n_subjects = 12, log_k_pop = log(0.01), seed = 7)
trt <- simulate_dd_choice(n_subjects = 12, log_k_pop = log(0.04), seed = 8)
trt$id <- paste0("t", trt$id)
ctrl$group <- "ctrl"
trt$group <- "treat"
choice_data <- rbind(ctrl, trt)
fit_choice <- fit_dd_choice(choice_data, mode = "structural", factors = "group")
get_dd_param_emms(fit_choice)
get_dd_comparisons(fit_choice)$k$contrasts_ratio
# A tibble: 2 × 6
level k k_log std.error conf.low conf.high
<chr> <dbl> <dbl> <dbl> <dbl> <dbl>
1 group=ctrl 0.0113 -4.48 0.234 0.00716 0.0179
2 group=treat 0.0369 -3.30 0.212 0.0243 0.0559
# A tibble: 1 × 5
contrast ratio conf.low conf.high p.value
<chr> <dbl> <dbl> <dbl> <dbl>
1 group=ctrl - group=treat 0.307 0.167 0.566 0.000152
If your choices come from the 27-item MCQ, mcq27_to_choice() reshapes
the long-form responses into the per-trial
id/ss_amount/ll_amount/delay/choice frame that
fit_dd_choice() expects, using the Kirby, Petry, & Bickel (1999) item
design:
head(mcq27_to_choice(mcq27))
# A tibble: 6 × 5
id ss_amount ll_amount delay choice
<chr> <dbl> <dbl> <dbl> <dbl>
1 1 54 55 117 0
2 1 55 75 61 0
3 1 19 25 53 0
4 1 31 85 7 1
5 1 14 25 19 1
6 1 47 50 160 0
For a Bayesian treatment, fit_dd_brms() and fit_dd_choice_brms() fit
the same models via brms and Stan, with the discount rate estimated on
the same natural-log scale. This is a development-version feature, and
brms (along with posterior and loo) is a suggested package, so install
it first. fit_dd_brms() covers all four indifference-point equations;
fit_dd_choice_brms() implements the structural choice model (Mazur or
exponential) in v1.
fit_b <- fit_dd_brms(dd_ip,
equation = "mazur", family = "beta",
chains = 4, iter = 2000, cores = 4, seed = 1
)
summary(fit_b)
Bayesian Mixed-Effects Discounting Model Summary (brms)
==================================================
Equation: mazur Family: beta
Backend: brms
Converged: Yes
Subjects: 100 Observations: 600
Diagnostics: rhat_max = 1.005, divergences = 0, min bulk ESS = 559
Coefficients (posterior median / SD, natural scale):
term_display estimate std.error
k:(Intercept) 0.325 0.03308
Variance components:
Component Estimate Scale
sigma_u (log10-k RE SD) 0.4286 log10
phi (precision) 28.5854 natural
The S3 surface mirrors the TMB tier: tidy(), glance() (reporting
elpd_loo/looic and MCMC diagnostics in place of AIC/BIC),
confint() (quantile credible intervals), ranef(), and predict().
get_dd_param_emms() and get_dd_comparisons() accept brms fits too,
returning credible intervals and the posterior probability of direction
in place of adjusted p-values. The Bayesian discounting
vignette
covers priors, boundary handling, and diagnostics in full.
dd_out <- calc_dd(five.fivetrial_dd)
knitr::kable(dd_out, caption = "Scoring Summary of the 5.5 Trial Delay Discounting Task")
| ResponseId | index | q | firstclick | lastclick | pagesubmit | totalclicks | response | attentionflag | kval | ed50 |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | I16 | 1 | 1.761 | 1.761 | 3.337 | 1 | ll | No | 0.0067058 | 149.1249275 |
| 1 | I24 | 2 | 7.729 | 7.729 | 8.457 | 1 | ss | No | 0.0067058 | 149.1249275 |
| 1 | I20 | 3 | 1.558 | 1.558 | 3.377 | 1 | ll | No | 0.0067058 | 149.1249275 |
| 1 | I22 | 4 | 2.333 | 3.949 | 4.501 | 2 | ss | No | 0.0067058 | 149.1249275 |
| 1 | I21 | 5 | 3.161 | 3.161 | 3.728 | 1 | ss | No | 0.0067058 | 149.1249275 |
| 2 | I16 | 1 | 3.779 | 3.779 | 4.351 | 1 | ss | No | 4.8989795 | 0.2041241 |
| 2 | I8 | 2 | 1.454 | 1.454 | 3.190 | 1 | ss | No | 4.8989795 | 0.2041241 |
| 2 | I4 | 3 | 1.179 | 1.179 | 3.144 | 1 | ll | No | 4.8989795 | 0.2041241 |
| 2 | I6 | 4 | 0.873 | 0.873 | 3.256 | 1 | ss | No | 4.8989795 | 0.2041241 |
| 2 | I5 | 5 | 2.621 | 2.621 | 3.258 | 1 | ss | No | 4.8989795 | 0.2041241 |
| 3 | I16 | 1 | 1.115 | 1.115 | 3.272 | 1 | ss | Yes | NA | NA |
| 3 | I8 | 2 | 0.679 | 0.679 | 3.074 | 1 | ss | Yes | NA | NA |
| 3 | I4 | 3 | 0.606 | 0.606 | 3.044 | 1 | ss | Yes | NA | NA |
| 3 | I2 | 4 | 0.745 | 0.745 | 3.302 | 1 | ss | Yes | NA | NA |
| 3 | I1 | 5 | 0.924 | 0.924 | 4.181 | 1 | ss | Yes | NA | NA |
| 3 | AttendSS | 6 | 1.450 | 1.450 | 4.181 | 1 | ss | Yes | NA | NA |
| 4 | I16 | 1 | 1.011 | 1.011 | 3.190 | 1 | ll | Yes | NA | NA |
| 4 | I24 | 2 | 1.041 | 1.041 | 3.109 | 1 | ll | Yes | NA | NA |
| 4 | I28 | 3 | 0.806 | 0.806 | 3.113 | 1 | ll | Yes | NA | NA |
| 4 | I30 | 4 | 0.822 | 0.822 | 3.487 | 1 | ll | Yes | NA | NA |
| 4 | I31 | 5 | 0.914 | 0.914 | 3.170 | 1 | ll | Yes | NA | NA |
| 4 | AttendLL | 6 | 2.158 | 2.158 | 3.573 | 1 | ll | Yes | NA | NA |
Scoring Summary of the 5.5 Trial Delay Discounting Task
pd_out <- calc_pd(five.fivetrial_pd)
knitr::kable(pd_out, caption = "Scoring Summary of the 5.5 Trial Probability Discounting Task")
| ResponseId | index | q | firstclick | lastclick | pagesubmit | totalclicks | response | attentionflag | hval | etheta50 | ep50 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | I16 | 1 | 3.980 | 3.980 | 5.184 | 1 | sc | No | 7.435436 | 0.1344911 | 88.14525 |
| 1 | I8 | 2 | 4.010 | 4.010 | 4.763 | 1 | lu | No | 7.435436 | 0.1344911 | 88.14525 |
| 1 | I12 | 3 | 2.061 | 2.061 | 3.252 | 1 | sc | No | 7.435436 | 0.1344911 | 88.14525 |
| 1 | I10 | 4 | 1.525 | 1.525 | 3.019 | 1 | sc | No | 7.435436 | 0.1344911 | 88.14525 |
| 1 | I9 | 5 | 2.253 | 2.954 | 3.738 | 2 | lu | No | 7.435436 | 0.1344911 | 88.14525 |
| 2 | I16 | 1 | 2.873 | 2.873 | 3.883 | 1 | sc | No | 99.000000 | 0.0101010 | 99.00000 |
| 2 | I8 | 2 | 3.745 | 3.745 | 4.864 | 1 | sc | No | 99.000000 | 0.0101010 | 99.00000 |
| 2 | I4 | 3 | 1.159 | 1.159 | 6.356 | 1 | sc | No | 99.000000 | 0.0101010 | 99.00000 |
| 2 | I2 | 4 | 3.064 | 3.064 | 5.408 | 1 | sc | No | 99.000000 | 0.0101010 | 99.00000 |
| 2 | I1 | 5 | 2.049 | 2.049 | 5.097 | 1 | sc | No | 99.000000 | 0.0101010 | 99.00000 |
| 2 | AttendSS | 6 | 2.295 | 2.295 | 4.641 | 1 | lu | No | 99.000000 | 0.0101010 | 99.00000 |
| 3 | I16 | 1 | 8.933 | 8.933 | 9.769 | 1 | sc | No | 1.601445 | 0.6244361 | 61.55983 |
| 3 | I8 | 2 | 2.163 | 2.163 | 2.981 | 1 | lu | No | 1.601445 | 0.6244361 | 61.55983 |
| 3 | I12 | 3 | 3.129 | 3.129 | 3.895 | 1 | lu | No | 1.601445 | 0.6244361 | 61.55983 |
| 3 | I14 | 4 | 2.655 | 2.655 | 4.855 | 1 | lu | No | 1.601445 | 0.6244361 | 61.55983 |
| 3 | I15 | 5 | 4.021 | 4.021 | 4.705 | 1 | sc | No | 1.601445 | 0.6244361 | 61.55983 |
| 4 | I16 | 1 | 4.415 | 4.415 | 5.382 | 1 | sc | No | 7.435436 | 0.1344911 | 88.14525 |
| 4 | I8 | 2 | 6.123 | 6.123 | 6.974 | 1 | lu | No | 7.435436 | 0.1344911 | 88.14525 |
| 4 | I12 | 3 | 1.673 | 1.673 | 3.191 | 1 | sc | No | 7.435436 | 0.1344911 | 88.14525 |
| 4 | I10 | 4 | 1.757 | 1.757 | 3.259 | 1 | sc | No | 7.435436 | 0.1344911 | 88.14525 |
| 4 | I9 | 5 | 1.207 | 1.207 | 4.592 | 1 | lu | No | 7.435436 | 0.1344911 | 88.14525 |
Scoring Summary of the 5.5 Trial Probability Discounting Task
Worked examples live in the package vignettes, also rendered on the website:
vignette("mcq27-scoring"))vignette("pdq-scoring"))vignette("delay-discounting-basics"))vignette("fivetrial-task"))vignette("linearized-mazur"))vignette("tmb-mixed-effects"))vignette("choice-discounting"))vignette("sltb-discounting"))vignette("dd-group-comparisons"))vignette("bayesian-discounting"))vignette("power-analysis"))To learn more about a function and what arguments it takes, type “?” in front of the function name.
?score_mcq
?score_mcq27
Kaplan, B. A., Amlung, M., Reed, D. D., Jarmolowicz, D. P., McKerchar, T. L., & Lemley, S. M. (2016). Automating scoring of delay discounting for the 21-and 27-item monetary choice questionnaires. The Behavior Analyst, 39, 293-304. https://doi.org/10.1007/s40614-016-0070-9
Reed, D. D., Niileksela, C. R., & Kaplan, B. A. (2013). Behavioral economics: A tutorial for behavior analysts in practice. Behavior Analysis in Practice, 6 (1), 34–54. https://doi.org/10.1007/BF03391790
Mazur, J. E. (1987). An adjusting procedure for studying delayed reinforcement. In M. L. Commons, J. E. Mazur, J. A. Nevin, & H. Rachlin (Eds.), The effect of delay and of intervening events on reinforcement value (pp. 55–73). Lawrence Erlbaum Associates, Inc.
Myerson, J., Green, L., & Warusawitharana, M. (2001). Area under the curve as a measure of discounting. Journal of the Experimental Analysis of Behavior, 76 (2), 235-243. https://doi.org/10.1901/jeab.2001.76-235
Borges, A. M., Kuang, J., Milhorn, H. and Yi, R. (2016), An alternative approach to calculating Area-Under-the-Curve (AUC) in delay discounting research. Journal of the Experimental Analysis of Behavior, 106, 145-155. https://doi.org/10.1002/jeab.219
Johnson, M. W., & Bickel, W. K. (2008). An algorithm for identifying nonsystematic delay-discounting data. Experimental and Clinical Psychopharmacology, 16 (3), 264-274. https://doi.org/10.1037/1064-1297.16.3.264
Kirby, K. N., & Marakovic, N. N. (1996). Delay-discounting probabilistic rewards: Rates decrease as amounts increase. Psychonomic Bulletin & Review, 3 (1), 100-104. https://doi.org/10.3758/BF03210748
Kirby, K. N., Petry, N. M., & Bickel, W. K. (1999). Heroin addicts have higher discount rates for delayed rewards than non-drug-using controls. Journal of Experimental Psychology: General, 128 (1), 78-87. https://doi.org/10.1037//0096-3445.128.1.78
Young, M. E. (2017). Discounting: A practical guide to multilevel analysis of indifference data. Journal of the Experimental Analysis of Behavior, 108 (1), 97-112. https://doi.org/10.1002/jeab.265
Young, M. E. (2018). Discounting: A practical guide to multilevel analysis of choice data. Journal of the Experimental Analysis of Behavior, 109 (2), 293-312. https://doi.org/10.1002/jeab.316
Yeh, Y. H., Tegge, A. N., Freitas-Lemos, R., Myerson, J., Green, L., & Bickel, W. K. (2023). Discounting of delayed rewards: Missing data imputation for the 21-and 27-item monetary choice questionnaires. PLOS ONE, 18 (10), e0292258. https://doi.org/10.1371/journal.pone.0292258
Koffarnus, M. N., & Bickel, W. K. (2014). A 5-trial adjusting delay discounting task: accurate discount rates in less than one minute. Experimental and Clinical Psychopharmacology, 22(3), 222-228. https://doi.org/10.1037/a0035973
Koffarnus, M. N., Rzeszutek, M. J., & Kaplan, B. A. (2021). Additional discounting rates in less than one minute: Task variants for probability and a wider range of delays. https://doi.org/10.13140/RG.2.2.31281.92000
Koffarnus, M. N., Kaplan, B. A., & Stein, J. S. (2017). User guide for Qualtrics minute discounting template. https://doi.org/10.13140/RG.2.2.26495.79527
Kim, M., Koffarnus, M. N., & Franck, C. T. (2024). Thinking inside the bounds: Improved error distributions for indifference point data analysis and simulation via beta regression using common discounting functions.
Kim, M., Kaplan, B. A., Koffarnus, M. N., & Franck, C. T. (2025). Scale-location-truncated beta regression: Expanding beta regression to accommodate 0 and 1. arXiv. https://arxiv.org/abs/2509.13167
Maintained by Brent Kaplan. For statistical consulting and R/software development in behavioral economics, see codedbx.
